Description

Blum AVENTOS HK-XS Lift System - for Small Wall Cabinets and Built-Ins. a smaller, cost-effective lift system for shallow wall cabinets, like those above refrigerators and pantries. Its variable stop feature allows the door to stay in any desired position, so it's always within reach. The lift mechanism can also be used on one or both sides of the cabinet, making it a flexible option for many applications.
  • Power factor = cabinet height [inch] x door weight [lbs] (including cabinet handle weight)
  • NOTE: Double power factor when using two lift mechanisms.
  • Set Includes: (1ea) lift mechanism only. Hinges and mounting brackets (required) all sold separately.
  • Cabinet Dimensions:
  • Cabinet height: 9-3/8" - 24" (238mm-610mm)
  • Min. Inside cabinet depth: 4-7/8" (125mm). NOTE: Inside cabinet depth of 3-7/8" (100mm) or more is possible with special drilling position.
  • For Cabinet widths up to 72" (1828mm)
Features:
  • Use in conjunction with CLIP top BLUMOTION hinges for soft effortless closing.
  • Light operating forces.
  • Harmonious quality of motion with a variable stop.
  • Tool-free assembly.
  • Simple, infinitely variable adjustment of the lift mechanism.
  • Holds in any position: Adjust the lift mechanism precisely to the weight of the front and it will stay exactly where you want it to.
  • Applications: Slim construction ideal for small applications in wall cabinets, tall cabinets and over the refrigerator.
  • Design of fronts: Can be used with wood doors and wide or narrow aluminum frame doors. For large and heavy fronts, attach a lift mechanism to both sides of the cabinet.
  • Lift Mechanism for TIP-ON also available for handleless door fronts, easy to open with just a light touch

Required Accessories

Optional Accessories

Specifications

Manufacturer:
Blum
Manufacturer Location:
USA
Type:
lid support
California Residents:
WARNING: This product can expose you to chemicals including lead and/or wood dust, which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Additional:
  • We recommend the more powerful lift mechanism for applications in overlapping ranges. A trial application is recommended when you are in a borderline area of the individual lift mechanism's power factor range.
  • 105° Opening angle. For hinges with smaller opening angles, the opening angle will depend on the hinge used.

Installation / Specification Documents

Blum AVENTOS Catalog Blum AVENTOS HK-XS Series Brochure Installation Instructions - Narrow aluminum frame door application Installation Instructions - Wood/wide aluminum frame door application Blum AVENTOS Program Overview
